The SVOLT 23.2 Ah LiFePO4 pouch cell combines 3.2 V nominal voltage with 74.24 Wh of calculated nominal energy and a listed operating voltage range of 2.3–3.65 V. The supplied parameters distinguish AC and DC resistance and provide separate cycle-life claims for room temperature and 45°C. MisenBattery supplies cells and supports custom battery pack evaluation based on confirmed current limits, mechanical drawings, thermal requirements and application duty cycles.
01 23.2 Ah LiFePO4 Pouch Cell
The supplied parameters identify a lithium iron phosphate pouch cell with 23.2 Ah nominal capacity and 3.2 V nominal voltage. These ratings support preliminary series and parallel configuration studies. Multiplying nominal voltage by capacity gives 74.24 Wh per cell, with usable pack energy evaluated against the intended load, operating limits, temperature and protection settings.
02 Defined 2.3–3.65 V Operating Window
The listed operating voltage range is 2.3–3.65 V. This provides a reference for initial charger and BMS selection discussions, while charging method, current limits and protection margins require manufacturer confirmation. Validate cell voltage behavior, sensing accuracy and balancing requirements under the intended pack duty cycle before finalizing the operating thresholds.
03 Separate AC and DC Resistance Limits
AC resistance is listed below 1.5 mΩ, while DC resistance is listed below 3.5 mΩ. These are separate measurement categories and should remain distinct in technical comparisons. AC frequency, DC pulse duration, SOC and temperature are not supplied, so confirm the applicable test procedures before incoming inspection, cell matching or thermal modeling.
04 Dimensions with Stated Tolerances
Dimensions are supplied as 8.55 ± 0.3 × 92 ± 1 × 304 ± 1 mm, with an approximate weight of 460–480 g. Retaining these tolerances supports preliminary enclosure planning. Confirm the axis order and tab boundaries, and provide appropriate insulation, pouch swelling allowance, mechanical support and tab strain relief before pack tooling.
05 Cycle-Life References at Two Temperatures
The supplied table lists more than 5000 cycles at room temperature and more than 3000 cycles at 45°C. Test currents, SOC window and capacity-retention criteria are not supplied. Keep the two claims separate and confirm their underlying protocols before comparing service life or using them as targets for a specific application.
06 Temperature and Power-Density References
Charging is listed from −5 to +60°C and discharging from −20 to +60°C, with power density above 1300 W/kg. Current derating and the power test protocol are not supplied. Confirm charging controls across temperature and the duration, SOC and thermal conditions of the power figure before establishing pack current or power limits.
Custom battery pack applications: MisenBattery supplies SVOLT cells and supports custom pack evaluation for energy storage and industrial equipment projects, subject to confirmed model identity and application validation. Integration should include a compatible LiFePO4 BMS, fuse protection, voltage and temperature sensing, validated tab-welding and interconnect processes, insulation, cell spacing, swelling allowance and suitable thermal and mechanical design. Confirm applicable CE, UN38.3, RoHS and UL documentation for the specific cell, pack and shipment; certification status is not established by the supplied parameter table.
