Choosing a pouch cell for a custom battery pack is not simply a matter of finding the right voltage and capacity.
A cell may look suitable on paper but still create problems during module assembly, thermal testing or long-term operation. The discharge current may be too close to the cell limit. The tabs may not fit the busbar layout. The pack enclosure may leave no room for swelling. A battery management system may also be configured around the wrong voltage range.
These problems are easier and less expensive to solve during cell selection than after a prototype has already been built.
A reliable selection process should start with the complete battery system: application, working voltage, required energy, continuous and peak current, installation space, temperature range, service life and production volume.
This guide explains how engineers and product developers can evaluate pouch cells for electric vehicles, energy storage systems, robotics, drones, industrial equipment and other custom battery applications.
Before comparing cell models, prepare a basic battery requirement sheet.
At a minimum, it should include:
Application
Nominal pack voltage
Maximum charging voltage
Minimum operating voltage
Required capacity or energy
Continuous discharge current
Peak discharge current and duration
Maximum battery dimensions
Target battery weight
Charging time
Operating temperature
Required cycle life
Expected annual quantity
This information determines whether a cell is technically suitable.
For example, two projects may both require a 48V 100Ah battery pack. However, a stationary storage system operating at 30A has very different cell requirements from an industrial vehicle drawing 200A during acceleration.
The capacity may be the same, but the chemistry, internal resistance, tab design, thermal structure and battery management system may all be different.
The first major decision is the cell chemistry.
Misen supplies and evaluates several pouch cell technologies, including NMC, LFP, semi-solid and sodium-ion cells. Each chemistry serves a different project priority.
NMC pouch cells are widely used when energy density and battery weight are important.
Typical applications include:
Electric vehicles
Electric motorcycles
Robotics
Unmanned systems
Portable industrial equipment
Weight-sensitive battery modules
A conventional NMC pouch cell normally has a nominal voltage of approximately 3.6V to 3.7V. The standard maximum charging voltage is often 4.2V, although some high-voltage cells use a higher limit.
The exact charging voltage must always follow the cell specification. A BMS or charger designed for a standard 4.2V cell should not automatically be used with a high-voltage chemistry.
NMC is often a strong choice when the project needs more energy in a limited space. However, thermal management, current loading and voltage control require careful attention.
LFP pouch cells are commonly selected when cycle life, thermal stability and long-term reliability matter more than achieving the lowest possible pack weight.
A typical LFP cell has:
Nominal voltage around 3.2V
Maximum charging voltage around 3.65V
Common applications include:
Energy storage systems
Solar battery systems
Industrial backup power
Utility vehicles
Frequently cycled battery packs
Compared with NMC, LFP generally requires more cells or a larger volume to reach the same energy target. In return, it can provide a stable voltage platform and strong cycle performance when the battery is properly designed and operated.
Semi-solid pouch cells are considered for projects that require high energy density and reduced battery weight.
They may be suitable for:
Premium electric mobility
Long-endurance drones
Specialized robotics
Aerospace-related systems
Compact high-energy battery packs
The term “semi-solid” covers different cell designs, so it is important to evaluate the actual specification rather than relying on the technology name alone.
Energy density, discharge capability, cycle life, charging method and certification status can vary significantly between models.
Sodium-ion pouch cells are attracting interest in projects that value low-temperature performance, rate capability and material availability.
Potential applications include:
Cold-climate mobility
Low-temperature industrial equipment
Two-wheel vehicles
Backup power
Selected energy storage systems
Their voltage range differs from conventional lithium-ion cells. As a result, an existing lithium battery BMS or charger may not be suitable without changes to voltage thresholds, SOC estimation and balancing strategy.
Sodium-ion cells should therefore be evaluated as a complete system rather than treated as a direct drop-in replacement for NMC or LFP.
Lithium titanate cells can support high charge rates, long cycle life and low-temperature operation. However, their lower nominal voltage and lower energy density usually result in a larger and more expensive battery pack.
LTO may be appropriate for specialized fast-charging or high-cycle applications, but it is rarely the first option for projects focused on compact size or low cost.
| Cell chemistry | Main advantage | Main limitation | Typical applications |
|---|---|---|---|
| NMC | High energy density and lower weight | Requires careful thermal and voltage management | EVs, robotics, UAVs and portable systems |
| LFP | Long cycle life and strong thermal stability | Lower energy density than NMC | ESS, industrial equipment and utility vehicles |
| Semi-solid | High-energy potential for premium projects | Model availability and cost vary | Lightweight and space-limited systems |
| Sodium-ion | Low-temperature and high-rate potential | Lower energy density and less mature supply chain | Cold-climate mobility and selected storage |
| LTO | Fast charging and long cycle life | Low energy density and higher system cost | High-cycle and rapid-charging applications |
There is no universally best pouch cell chemistry. The correct choice depends on which requirement cannot be compromised.
Once the chemistry is selected, the next step is determining how many cells must be connected in series.
Cells connected in series increase voltage. The capacity in ampere-hours remains approximately the same.
The basic relationship is:
Pack nominal voltage = Cell nominal voltage × Number of cells in series
A nominal 24V-class NMC battery may use seven cells in series:
3.7V × 7 = 25.9V
This is normally described as a 7S battery pack.
However, nominal voltage alone is not enough. The following values must also be checked:
Maximum pack charging voltage
Minimum pack operating voltage
Equipment input voltage range
Charger output voltage
BMS overcharge threshold
BMS over-discharge threshold
For a standard 7S NMC pack using cells charged to 4.2V:
Maximum pack voltage = 4.2V × 7 = 29.4V
The equipment, charger and BMS must all be compatible with this upper voltage.
The same “24V” product description can refer to different battery systems. A 24V lead-acid replacement, a 7S NMC battery and an 8S LFP battery do not have identical voltage curves.
For this reason, selecting the series count should be based on the device’s complete operating voltage window, not only its advertised voltage.
Capacity is usually stated in ampere-hours, but battery pack selection should also consider watt-hours.
The basic relationship is:
Energy in Wh = Nominal voltage × Capacity in Ah
For example:
48V × 100Ah = 4,800Wh
This gives a better indication of stored energy than the Ah value alone.
A 12V 100Ah battery and a 48V 100Ah battery have the same ampere-hour rating, but the 48V battery stores approximately four times as much energy.
The theoretical energy on the label is not always the energy available to the equipment.
Usable capacity can be affected by:
BMS voltage limits
Selected SOC operating window
Discharge rate
Ambient temperature
Voltage drop under load
Converter efficiency
Cell ageing
Required reserve capacity
A project that needs 4kWh of usable energy may therefore require more than 4kWh of nominal cell energy.
The correct reserve depends on the application. A stationary system with predictable loads can be evaluated differently from a vehicle that must still operate after several years of capacity loss.
Cells connected in parallel increase capacity and current capability while keeping the voltage approximately the same.
A 2P configuration uses two cells in parallel. A 3P configuration uses three.
Where possible, a larger-capacity single cell may reduce:
Number of welds
Number of busbar connections
Insulation parts
Assembly time
Potential connection failures
However, multiple smaller cells may offer better flexibility when the available space is irregular or when a specific current distribution is required.
The best configuration depends on the cell dimensions, module structure, heat distribution and production method. Fewer cells do not automatically guarantee a better battery pack.
The discharge rate of a cell is normally expressed as a C-rate.
For a 50Ah cell:
1C equals 50A
2C equals 100A
3C equals 150A
This calculation is simple, but selecting a high-rate cell requires more than checking the maximum current shown in a specification table.
Continuous current is the maximum current the battery must deliver during normal operation for an extended period.
It affects:
Cell temperature
Voltage drop
Usable capacity
Connector selection
Busbar thickness
Cable size
BMS current rating
Cooling requirements
A cell rated for a certain current under laboratory conditions may run hotter inside a tightly enclosed module. Compression plates, insulation materials and neighbouring cells can all influence heat dissipation.
Peak current occurs during short high-power events such as:
Motor startup
Acceleration
Hydraulic pump activation
UAV take-off
Tool impact
Short-duration emergency loads
A peak current specification is incomplete unless the duration is also known.
A cell capable of delivering 300A for two seconds may not support the same current for 30 seconds. Peak current must therefore be specified together with its duration and repetition frequency.
A battery should not operate continuously at the maximum advertised cell current without thermal verification.
A preliminary design margin is normally recommended, but there is no universal percentage suitable for every project. The required margin depends on:
Ambient temperature
Cooling conditions
Pack enclosure
Cell ageing
Current duty cycle
Acceptable temperature rise
Required service life
For demanding applications, prototype testing should include cell temperature, tab temperature, voltage drop and DC internal resistance under the actual load profile.
Pouch cells are attractive because they can provide high packaging efficiency and flexible dimensions.
Their format is commonly described as:
Thickness × Width × Length
However, the listed cell dimensions are only one part of the mechanical design.
A pack designer must also allow space for:
Cell tabs
Busbars
Insulation sheets
Compression plates
Cushioning materials
Thermal interfaces
BMS
Wiring
Connectors
Fuses
Assembly tolerances
Pouch cells can change thickness during charging, cycling and ageing.
The required allowance should be based on the cell supplier’s data, expected SOC range, cycle-life target and compression strategy. A fixed percentage should not be applied blindly across all cell models.
Leaving too little space can create excessive mechanical stress. Leaving the cells completely unsupported can also lead to uneven swelling, poor contact and reduced module stability.
A suitable mechanical structure should control expansion while avoiding damaging pressure on the cell body or sealing area.
Pouch cell tabs may be located:
On the same side
On opposite sides
At different offsets
In custom orientations
The tab arrangement affects the module layout, busbar design and assembly process.
The designer should verify:
Positive and negative tab positions
Tab width and thickness
Tab material
Welding method
Required current
Bending limitations
Clearance from the sealing edge
A technically suitable cell can still be difficult to use if its tab layout conflicts with the enclosure or BMS position.
Cycle life is often defined as the number of charge and discharge cycles completed before capacity falls to a specified level, commonly 80% of the initial capacity.
However, a cycle-life number is only meaningful when the test conditions are known.
Important conditions include:
Charge rate
Discharge rate
Depth of discharge
Upper charging voltage
Lower discharge voltage
Test temperature
Rest time
Cell compression
End-of-life capacity threshold
Two cells both advertised with 2,000 cycles may have been tested under very different conditions.
Cycle life measures ageing caused by repeated charge and discharge.
Calendar life measures degradation over time, including periods when the battery is not cycling.
A battery stored for long periods at high SOC and high temperature may lose capacity even when it completes very few cycles.
For products expected to remain in service for five to ten years, both cycle life and calendar ageing should be considered.
LFP cells often provide strong cycle performance, while NMC cells are frequently selected for higher energy density. But the final service life is also affected by pack design and operating strategy.
The following measures can improve battery life:
Avoiding unnecessary high charging voltage
Reducing continuous high-current operation
Controlling cell temperature
Limiting extreme depth of discharge
Maintaining cell consistency
Using suitable compression
Setting accurate BMS limits
Selecting a long-life cell cannot compensate for an unsuitable thermal or mechanical design.
Temperature affects available capacity, power capability, charging behaviour and ageing.
For cold-climate applications, check:
Discharge capacity at the required temperature
Voltage drop under load
Maximum charging current at low temperature
Whether charging below 0°C is permitted
Whether cell heating is required
BMS temperature protection settings
A cell that can discharge at -20°C may still have strict low-temperature charging limitations.
For high-temperature applications, check:
Continuous current derating
Cell surface temperature
Internal heat accumulation
Enclosure ventilation
Cooling method
Storage temperature
Expected calendar ageing
The operating temperature written on a datasheet should not be interpreted as a guarantee that the cell can deliver full power throughout that entire range.
Even when every cell comes from the same model, differences can exist in capacity, voltage, resistance and self-discharge behaviour.
These differences become more important when many cells are connected in series.
A weak or inconsistent cell may reach the charge or discharge limit before the rest of the pack. This can reduce usable capacity and cause the BMS to interrupt operation earlier than expected.
Depending on the project, pouch cell matching may include:
Capacity grading
Open-circuit voltage comparison
AC internal resistance testing
DC internal resistance evaluation
K-value screening
Thickness and dimension inspection
Appearance and sealing inspection
Batch traceability
For high-capacity modules, cell consistency is not only a quality-control issue. It directly affects pack balance, temperature distribution, usable energy and long-term reliability.
Misen can support pouch cell testing and matching according to the requirements of the selected model and project.
The BMS must be selected after the cell chemistry, series count and current requirements are confirmed.
Important BMS parameters include:
Number of cells in series
Overcharge voltage
Over-discharge voltage
Continuous current
Peak current
Overcurrent delay
Short-circuit protection
Balancing current
Temperature sensors
Communication protocol
Charging and discharge architecture
A BMS designed for LFP should not automatically be used with NMC or sodium-ion cells. The voltage thresholds and SOC calculation may be unsuitable.
The BMS must also be coordinated with the charger and equipment. It should protect the battery without interrupting normal startup currents or creating conflicts with external protection systems.
A custom pouch battery pack is a mechanical, electrical and thermal system.
The final design may need to include:
Cell compression structure
End plates
Insulation barriers
Cell holders
Busbars
Fuses
Temperature sensors
Thermal interface materials
Cooling channels
BMS
Main connector
Service connector
Pack enclosure
Venting or pressure-relief strategy
This is why selecting a pouch cell only from a catalogue image or capacity value can be risky.
The cell and module should be evaluated together.
| Selection factor | Questions to confirm |
|---|---|
| Application | What equipment will the battery power? |
| Chemistry | Is energy density, cycle life, rate capability or low-temperature performance the priority? |
| Voltage | What are the nominal, maximum and minimum system voltages? |
| Capacity | How much nominal and usable energy is required? |
| Current | What are the continuous and peak currents, and how long does the peak last? |
| Dimensions | What is the maximum pack size after allowing for BMS, wiring, insulation and compression? |
| Weight | Is the project weight-sensitive? |
| Temperature | What are the charging, discharging and storage temperatures? |
| Cycle life | What test conditions and end-of-life capacity are required? |
| Cell matching | What limits are required for capacity, OCV, resistance and K-value? |
| BMS | What protection, balancing and communication functions are needed? |
| Quantity | Is the project in sampling, pilot production or mass production? |
Several mistakes appear repeatedly during custom battery projects.
Two cells with the same Ah rating may have very different voltage, resistance, size, weight and discharge capability.
Peak current without a duration is not enough to evaluate the cell, BMS or busbar.
An enclosure may not apply even pressure across the cell surface. A dedicated module structure may still be required.
A pouch cell should not be installed in a rigid cavity based only on its new-cell thickness.
This is especially risky when changing between NMC, LFP, high-voltage lithium-ion or sodium-ion cells.
Cells from different batches or with large capacity and resistance differences can reduce battery performance.
The complete pack must be tested under the real load profile and thermal environment.
The best pouch cell is not necessarily the cell with the highest capacity, energy density or discharge rate.
It is the cell that fits the complete battery system.
A successful selection should balance:
Voltage compatibility
Required energy
Continuous and peak power
Available space
Battery weight
Cycle-life target
Temperature conditions
Mechanical structure
Cell consistency
BMS requirements
Production and supply stability
Misen supports customers from initial pouch cell selection through testing, matching, module compression, BMS evaluation and battery pack integration.
Available options include NMC, LFP, semi-solid and sodium-ion pouch cells for electric mobility, energy storage, UAVs, robotics and industrial battery projects.
To evaluate a project, send the following information:
Application
Required pack voltage
Required capacity
Continuous discharge current
Peak current and duration
Maximum battery dimensions
Operating temperature
Cycle-life target
Preferred chemistry
Estimated quantity
Based on these requirements, Misen can compare suitable pouch cell models and discuss the series-parallel configuration, cell matching, compression structure, BMS and prototype plan.
