As the global demand for high-performance lithium batteries continues to grow, the SK On SK77.7Ah pouch cell has become one of the most popular solutions in the energy storage retrofit, EV conversion, and second-life battery markets.
Thanks to its high energy density, lightweight structure, and strong discharge capability, the SK77.7 pouch lithium battery is widely used in:
DIY EV battery packs
Low-speed electric vehicles
Energy storage systems (ESS)
Marine battery applications
UAV and high-power projects
However, for professional B2B battery buyers and pack assemblers, understanding the technical risks behind pouch cells is critical.
In this article, we will analyze the three most common issues found in SK77.7 pouch lithium batteries:
Cell swelling
Voltage difference (voltage gap)
Internal resistance consistency
This guide will help importers, wholesalers, and battery pack manufacturers reduce procurement risks and improve pack reliability.
Unlike cylindrical or prismatic cells, pouch lithium batteries use aluminum-plastic film packaging. While this design improves energy density and weight efficiency, it also makes the cell more sensitive to internal gas generation.
Several factors can cause pouch cell swelling:
When lithium-ion cells operate beyond their safe voltage range, electrolyte decomposition may occur, generating gases such as:
CO2, CH4CO_2,\ CH_4CO2, CH4
These gases accumulate inside the pouch and create visible expansion.
Although pouch cells usually have good thermal dissipation, long-term operation above:
60∘C60^\circ C60∘C
can accelerate side reactions and gas formation.
If electrode drying is insufficient during production, trace moisture may react with the electrolyte over time. This hidden chemical reaction is one of the most common reasons for slow swelling in aged inventory cells.
When sourcing SK77.7 dismantled modules or warehouse stock, always inspect:
Surface flatness
Corner deformation
Edge expansion
Aluminum film tension
Minor physical deformation caused by transportation pressure may not affect usability. However, obvious “bread-like” swelling usually indicates internal chemical damage and should never enter battery pack assembly.
In lithium battery pack assembly, voltage consistency directly affects cycle life and BMS balancing performance.
There are two important concepts:
Static voltage difference
Dynamic voltage difference
For high-quality SK77.7 pouch cells from the same batch, the resting voltage gap should ideally remain within:
5mV∼10mV5mV\sim10mV5mV∼10mV
If the voltage difference exceeds:
30mV30mV30mV
it may indicate abnormal self-discharge behavior or cell aging.
Cells with high self-discharge rates will gradually become the weakest point in the battery pack, increasing balancing workload and reducing system lifespan.
During high-current discharge testing, especially near the end of discharge, weak cells often experience faster voltage drop compared to other cells.
This phenomenon usually means:
Capacity degradation
Increased internal resistance
Lithium plating or aging
For battery traders and pack integrators, large dynamic voltage gaps can significantly increase sorting and balancing costs.
Internal resistance (IR) is one of the most important indicators of lithium battery quality.
It directly affects:
Heat generation
Power capability
Efficiency
Cycle life
For normal SK77.7 ternary lithium pouch cells, AC internal resistance is commonly around:
0.5mΩ∼0.8mΩ0.5m\Omega\sim0.8m\Omega0.5mΩ∼0.8mΩ
depending on the test equipment and SOC conditions.
Cells with higher resistance generate more heat during charging and discharging, increasing thermal runaway risks.
In a battery pack, overall performance is always limited by the weakest cell.
Even if most cells perform well, one high-resistance cell can reduce:
Effective capacity
Continuous discharge capability
Battery lifespan
To ensure high-quality SK77.7 pouch battery solutions, professional suppliers should follow strict sorting and storage standards.
Recommended consistency standards:
IR deviation within:
±0.05mΩ\pm0.05m\Omega±0.05mΩ
Voltage difference within:
10mV10mV10mV
Pouch cells should always be used with:
Compression fixtures
Aluminum brackets
Pressure plates
Proper mechanical preloading helps:
Reduce swelling
Stabilize electrode structure
Extend cycle life
Improve long-term consistency
Recommended storage environment:
25±5∘C25\pm5^\circ C25±5∘C
Humidity should remain below:
45%45\%45%
Proper storage significantly slows aging and self-discharge.
Despite these technical challenges, the SK77.7 pouch lithium battery is still highly favored in the global B2B market because of its:
High energy density
Lightweight design
Strong discharge capability
Excellent space utilization
Competitive cost-performance ratio
For experienced battery pack manufacturers, proper grading and testing can greatly reduce failure risks.
When purchasing SK77.7 pouch cells, focusing only on capacity is not enough.
Professional buyers should also evaluate:
Swelling condition
Voltage consistency
Internal resistance matching
Storage history
Batch traceability
